Initial Access
To access the N-Squared SRP GUI, use a web browser (Microsoft Edge, Google Chrome, Mozilla Firefox, Apple Safari, and all derivatives of these browsers) and access the URL where the SRP GUI instance has been installed.
The SRP GUI instance is the SRP server which has been identified as the main server to which all configuration is to be applied prior to being synced with all SRP servers. This may be a dedicated SMS node, or any of the SRP service nodes which may also act as the primary instance.
When the SRP GUI is configured with OAuth support, the web browser will redirect you to the related provider’s login page (e.g. the Office465 login page). However when local authentication is used, accessing the N-Squared SRP GUI will display the login page.
To log in to a newly-installed SRP instance, use the default username and password:
| Username | admin |
| Password | admin |
After login, the default Announcements page will be displayed. Before performing any announcement configuration, navigate to the Admin page to update the administrator password:
Additionally, the menu includes links for the following:
| Menu | Description |
|---|---|
| Announcements | The announcement ID to audio file mapping. |
| Files | The configuration for per-language audio files. |
| Variable Parts | The configuration for per-language audio files necessary for the playback of variable parts, such as numbers and dates. |
| Snapshots | Allows an administrator to create and review historical snapshots of audio data and configuration against the current working copy. |
| Syncs | Allows an administrator to synchronise the primary audio data and configuration to all SRP servers. |
| Admin | Allows an administrator to create GUI groups and users. Available only when the SRP GUI is deployed with local user access, or file-based synchronisation. If a deployment uses OAuth for user management and database synchronisation, this admin menu will not be provided. |
| Update Password | Allows a user to update their own password. |
| Logout | Performs a secure logout for the current user. |
